Product Overview
The Allen & Heath SQ-7 is a professional digital mixer designed for live sound‚ AV‚ and installation applications. It offers 48 mixing channels‚ robust XCVI processing‚ and a compact‚ durable build‚ making it ideal for demanding audio environments.
1.1 Key Features of the Allen & Heath SQ-7
The Allen & Heath SQ-7 is a professional digital mixer featuring 48 channels‚ 32 XLR mic/line inputs‚ and 16 TRS line inputs. It includes 16 analog outputs‚ 8 stereo FX processors‚ and a 96kHz sample rate for high-quality audio processing. The mixer is built on Allen & Heath’s XCVI FPGA core‚ offering ultra-low latency and advanced DEEP processing. It supports Dante‚ MADI‚ and other expandable I/O options‚ making it versatile for live sound‚ AV‚ and installation applications. The SQ-7 also includes a 7-inch touchscreen‚ 33 faders‚ and 6 assignable layers for intuitive control. Its robust design and comprehensive features make it a top choice for professional audio engineers.
1.2 Design and Build Quality
The Allen & Heath SQ-7 is crafted with a focus on durability and reliability‚ featuring a sturdy‚ compact design. Its dimensions are 804mm (width)‚ 514.9mm (depth)‚ and 198mm (height)‚ with a weight of 17‚800 grams‚ ensuring stability in demanding environments. The mixer boasts a robust chassis and high-quality components‚ reflecting Allen & Heath’s commitment to professional-grade equipment. The 7-inch touchscreen and 33 faders are seamlessly integrated into the design‚ offering intuitive control. Built on the XCVI FPGA core‚ the SQ-7 combines innovative engineering with a user-centric layout‚ making it both functional and long-lasting for live sound‚ AV‚ and installation applications. Its build quality ensures reliability and performance in the most challenging settings.
1.3 Target Applications (Live Sound‚ AV‚ Installation)
The Allen & Heath SQ-7 is designed for professional audio environments‚ including live sound‚ AV installations‚ and fixed installations. Its versatility and high channel count make it ideal for managing large-scale live performances‚ corporate events‚ and worship services. Additionally‚ its compact size and extensive connectivity options suit AV installations in venues like theaters‚ conference halls‚ and houses of worship. The SQ-7’s flexible architecture also caters to installation scenarios‚ offering seamless integration with remote audio units and option cards. This mixer is a reliable solution for audio professionals requiring a powerful‚ adaptable‚ and high-performance system across diverse applications.
Technical Specifications
The Allen & Heath SQ-7 features 48 mixing channels‚ XCVI processing core‚ 96kHz sample rate‚ and low latency. It supports expandability with remote audio units and option cards.
2.1 Input/Output Configuration
The Allen & Heath SQ-7 offers a comprehensive input/output configuration‚ featuring 32 XLR mic/line inputs and 16 TRS line inputs‚ providing flexibility for various audio sources. It also includes 16 analog outputs‚ enabling precise control over sound distribution. Additionally‚ the SQ-7 supports expandability with remote audio units and option cards‚ allowing seamless integration into larger systems. This versatile configuration makes it suitable for live sound‚ AV‚ and installation environments‚ ensuring high-quality audio processing and reliable performance.
2.2 Digital Processing and Sample Rate
The Allen & Heath SQ-7 is powered by a high-performance XCVI digital processing engine‚ delivering 96kHz sample rate for pristine audio quality. This advanced processing ensures ultra-low latency and precise control over audio signals. The SQ-7 supports variable bit-depth processing‚ optimizing audio fidelity for professional applications. Its robust digital architecture allows for customizable processing options‚ making it adaptable to diverse live sound and installation needs. With its cutting-edge technology‚ the SQ-7 maintains exceptional sound clarity and operational reliability‚ solidifying its position as a leading choice for audio professionals.
2.3 Physical Dimensions and Weight
The Allen & Heath SQ-7 mixer measures 804mm in width‚ 514.9mm in depth‚ and 198mm in height‚ making it a compact yet robust unit. It weighs approximately 17.8kg‚ ensuring durability without compromising portability. The package dimensions are slightly larger‚ at 960mm in width‚ 685mm in depth‚ and an additional height that accommodates the mixer and accessories. These measurements ensure the SQ-7 fits neatly into various live sound and installation environments‚ providing a balance between size and functionality. Its sturdy design and manageable weight make it ideal for both stationary and mobile audio setups.
Manual Overview
The Allen & Heath SQ-7 manual provides comprehensive guidance‚ including safety information‚ firmware updates‚ and operational instructions‚ ensuring users can maximize the mixer’s capabilities effectively.
The SQ-7 manual introduces users to the mixer’s hardware and operational principles‚ providing a detailed overview to help professionals navigate its advanced features. It covers setup‚ controls‚ and safety guidelines‚ ensuring optimal performance in live sound and AV environments. The manual is structured to guide users from initial installation to advanced configurations‚ making it an essential resource for both novice and experienced engineers. By following the manual‚ users can unlock the full potential of the SQ-7‚ ensuring seamless integration into their audio workflows. This comprehensive guide is designed to enhance productivity and efficiency.
3.2 Important Safety Information
The SQ-7 manual emphasizes critical safety precautions to ensure safe operation and prevent damage. Users are advised to read the safety instructions sheet (AP9240/CL1-1) provided with the mixer. Proper handling‚ avoiding exposure to water‚ and maintaining good ventilation are highlighted. The mixer should not be operated in extreme temperatures (beyond 5 to 35°C) or in humid environments. Additionally‚ users are warned against modifying the equipment without authorization‚ as this could void the warranty or pose safety risks. Adhering to these guidelines ensures safe use and optimal performance of the SQ-7 mixer. Safety is paramount to protect both the operator and the equipment.
3.3 Firmware Update Instructions
Updating the SQ-7 firmware is essential for maintaining optimal performance and accessing new features. Users are instructed to download the latest firmware from the Allen & Heath website. Before proceeding‚ ensure the mixer is connected to a stable power source and all audio sessions are saved; The update process involves loading the firmware file through the mixer’s interface‚ following on-screen prompts‚ and allowing the system to restart. It is crucial to avoid interrupting the update to prevent system corruption. Detailed steps are outlined in the manual‚ ensuring a smooth and successful firmware upgrade. Regular updates ensure the mixer remains up-to-date with the latest enhancements and improvements.
Operational Guide
The SQ-7’s intuitive design features a 7-inch touch screen‚ 32 faders‚ and a rotary encoder for efficient navigation. Channels are easily configured using the dedicated controls.
4.1 Physical Controls and Layout
The SQ-7 features a 7-inch capacitive touchscreen‚ offering intuitive navigation and access to all mixer functions. Beneath the screen‚ 32 faders with LED meters provide precise control over channel levels. The surface is logically divided into sections‚ including channel strips‚ master controls‚ and a dedicated area for custom soft keys. The mixer also includes a rotary encoder for adjusting parameters and a set of transport controls for playback and recording. The ergonomic layout ensures easy access to all functions‚ making it ideal for live sound engineers who need to make quick adjustments during performances.
4.2 Channel Types and Configuration
The SQ-7 supports a variety of channel types‚ including mono‚ stereo‚ and master channels‚ each with customizable configurations. Mono channels are ideal for vocals and instruments‚ while stereo channels are designed for keyboards and playback sources. Master channels provide final output control‚ with options for L/R‚ mono‚ and aux mixes. The mixer allows users to assign channels to fader layers‚ enabling quick access during live performances. Configuration options include input sourcing‚ routing‚ and processing assignments‚ ensuring flexibility for diverse applications. The intuitive interface simplifies channel setup‚ with color-coded displays and clear organization for efficient workflow. This versatility makes the SQ-7 adaptable to both live sound and installation scenarios.
4.3 Connections and Signal Flow
The SQ-7 provides comprehensive connectivity options‚ ensuring seamless signal flow for professional audio setups. It features 32 XLR mic/line inputs and 16 TRS line inputs‚ alongside 16 analog outputs. Digital connectivity is supported through Dante‚ MADI‚ and other expandable network options. The mixer’s signal flow is highly customizable‚ allowing users to route inputs to channels‚ processing‚ and outputs with ease. The SQ-7 also supports remote I/O expanders‚ enabling scalable configurations for complex audio systems. Clear visual representations of signal paths and routing options within the interface simplify setup‚ making it intuitive to manage even the most intricate audio configurations. This flexibility ensures the SQ-7 meets the demands of live sound and installation environments.
Advanced Features
The SQ-7 offers advanced features like GEQ‚ effects processing‚ and layer navigation‚ enhancing workflow efficiency and sound quality for professional audio applications.
5.1 GEQ (Graphic Equalizer) and Processing
The Allen & Heath SQ-7 features a comprehensive GEQ section‚ allowing precise control over frequencies. With 32-band graphic equalizers‚ users can fine-tune audio for clarity and balance. The SQ-7 also supports parametric EQs‚ offering flexibility in shaping sound. Advanced processing options include compressors‚ gates‚ and limiters‚ ensuring optimal dynamic control. These tools are accessible via the console’s intuitive interface‚ enabling quick adjustments. The SQ-7’s processing capabilities are designed to handle complex audio scenarios‚ making it a powerful tool for live sound engineers and audio professionals. Its high-resolution displays provide clear visual feedback‚ aiding in precise adjustments during performances.
5.2 Effects and Processing Options
The Allen & Heath SQ-7 offers an extensive suite of effects and processing tools‚ enhancing creative control over audio. It includes a range of built-in effects such as reverbs‚ delays‚ choruses‚ and more‚ all customizable to suit specific needs. Users can assign effects to individual channels or master outputs‚ with the ability to adjust parameters like level‚ decay‚ and tone. Additionally‚ the SQ-7 supports DEEP processing‚ allowing integration of third-party plug-ins for expanded creative possibilities. With 8 stereo effects processors‚ the mixer provides flexibility for complex audio setups‚ ensuring high-quality sound processing in live and installed environments. This versatility makes it a favorite among audio engineers.
5.3 Layer Navigation and Workflow
The Allen & Heath SQ-7 features an intuitive layer navigation system‚ allowing seamless access to all channels and controls. Its 6 fader layers provide quick access to different channel groups‚ while the 16 assignable SoftKeys offer customizable shortcuts for frequently used functions. The SQ-7’s workflow is designed to minimize distractions‚ with a clear interface that simplifies complex tasks. Users can easily navigate between layers‚ assign channels‚ and adjust settings without disrupting the mixing process. This efficient design ensures a smooth and efficient workflow‚ making it ideal for live performances and installations where precision and speed are critical. The SQ-7’s layer system enhances productivity‚ allowing engineers to focus on delivering exceptional sound quality.
Accessories and Support
The SQ-7 is supported by a range of accessories‚ including dust covers‚ mounting brackets‚ and customizable control options. Comprehensive customer support‚ detailed manuals‚ and firmware updates ensure optimal performance and user satisfaction.
The SQ-7 is complemented by a variety of accessories designed to enhance its functionality and protection. A detachable metal bracket (SQ-BRACKET) allows for secure mounting of tablets or iPads‚ ensuring convenient control during performances. Additionally‚ a water-repellent polyester dust cover (AP11334) is available‚ featuring the Allen & Heath logo‚ to protect the mixer from dust and moisture when not in use. These accessories are crafted to match the mixer’s durability and aesthetic‚ offering practical solutions for professionals seeking to maintain and expand their SQ-7 setup. Allen & Heath provides comprehensive support for the SQ-7‚ ensuring users have access to the latest resources and assistance. The official website offers downloadable firmware updates‚ reference guides‚ and user manuals to keep the mixer up-to-date and functioning optimally. Additionally‚ detailed technical datasheets and quick start guides are available for troubleshooting and understanding advanced features. Customers can also register their SQ-7 to receive notifications about new firmware releases and product updates. With a dedicated customer support team and extensive online documentation‚ users can rely on Allen & Heath to address any inquiries or challenges they may encounter. This ensures a seamless and professional mixing experience.6.1 Compatible Accessories (e.g.‚ Brackets‚ Covers)
6.2 Customer Support and Resources
